Build-in power adapter;
● Support thermal paper roll , adhesive paper
● 2M FLASH and DRAM memory;
● 3~5inch/s ultra high print speed;
● Label paper auto position;
● Support Chinese and Korean Character;
● Support peel-off and tear-off modes;
● Compatible with various label softwares;
● Support printing media width from 25mm to 80mm;easy to operate
● Auto temperature control for durable printing
| Printing |
Print method |
Direct thermal line |
| Resolution |
203DPI |
| Print speed |
3 ~ 5inch/s |
| Interface |
USB |
| Print head |
Temperatur sensor: thermal sensitive ressistance
Pisition sensor: microswith |
| Paper presence |
Photoelectricity sensor |
| Memory |
DRAM: 2M FLASH: 2M |
| Character Size |
FONT O to FONT 8
Simplified/Traditional Chinese /Korean |
| Barcode |
Enlargement&Rotation |
1to10 times enlargement in both directions
0°、90°、270°、360°rotation |
| Barcode mode |
UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/
CODABAR/CODE93/CODE128 |
| Fonts |
GB2312 |
| Media |
Media width |
25 ~ 80mm |
| Media diameter |
100mm
|
| Power |
Cashdrawer out |
DC 24V/1A |
| Power supply |
AC 110V/220V，50 ~ 60Hz，DC 24V/2A |
Physical
properties |
Weight |
1.40kg |
| Dimension |
215×148×155mm |
| Environment |
Work environment |
Temperature: 0 ~ 45℃， Humidity: 10 ~ 80% |
| Storage environment |
Temperature: -10 ~ 60℃ ，Humidity: 10 ~ 90% |
|
